RAVENOL ATF ULV D-M is a Ultra Low Viscosity (ULV) Automatic Transmission Fluid (ATF), designed on the basis of PAO (Polyalphaolefin), Ester and highquality hydrocrack oils with a special additive and inhibition, which ensure a perfect function of the automatic transmission.
RAVENOL ATF ULV D-M is an ATF (Automatic Transmission Fluid) developed for the latest 6, 8 and 10 speed automatic transmissions from Ford and GM.
RAVENOL ATF ULV D-M guarantees maximum wear protection in all operating conditions and offers reduced fuel consumption.
RAVENOL ATF ULV D-M was developed for use in 6, 8 and 10 speed automatic transmissions, especially from Ford and GM.
RAVENOL ATF ULV D-M is particularly suitable when the Ford WSS-M2C949-A specification is required.
It is recommended to flush with RAVENOL ATF ULV D-M before filling with RAVENOL ATF ULV D-M.
RAVENOL ATF ULV D-M is particularly suitable for
Ford 6-speed transmissions 6F15
Ford 8-speed automatic transmissions 8F24, 8F35, 8F40, 8F57
Ford 10-speed 10R60, 10R80-MHT, 10R80, 10R140
GM 10-speed 10L80 MF6, 10L90 MGL, 10L100 (Allison) MGM/MGU
Please observe the manufacturer's instructions and operating manual.
- Very good lubricating properties also at low temperatures in winter
- Protection of highly loaded gear components, thus extended service life
- Very low flow point
- Excellent oxidation stability
- Protection against wear and corrosion
- Well balanced friction properties
Technical Product Data
|Density at 20 °C||kg/m³||836||EN ISO 12185|
|Viscosity at 100 °C||mm²/s||4,4||DIN 51562-1|
|Viscosity at 40 °C||mm²/s||18,6||DIN 51562-1|
|Viscosity Index VI||149||DIN ISO 2909|
|Brookfield Viscosity at -40 °C||mPa*s||2970||ASTM D2983|
|Pourpoint||°C||-51||DIN ISO 3016|
All indicated data are approximate values and are subject to the commercial fluctuations.
