RAVENOL DCT-LV Fluid is a modern PAO (polyalphaolefin) based, full synthetic DCT (dual clutch transmission) oil, with a special additivation and inhibition, which ensure a proper function of the dual clutch transmission.
RAVENOL DCT-LV Fluid was developed for the use of the third generation in the 7-speed dual clutch transmission by Magna GETRAG especially for the Daimler specification MB 239.21.
RAVENOL DCT-LV Fluid guarantees an optimum of power transmission and excellent clutch performance under extreme loads in midsummer as well as at low temperatures in winter.
Application instructions
RAVENOL DCT-LV Fluid was specially developed for dual-clutch transmissions from various car manufacturers such as BMW, Ford, Mercedes, VW/Audi.
RAVENOL DCT-LV Fluid is used to lubricate clutches in 7-speed Magna GETRAG dual-clutch transmissions (7DCT300/ 6DCT200/ 6DCT150). It can be used in direct shift transmissions with wet or dry clutches.
Characteristics
- Very good lubricating ability even at low temperatures
- A high, stable viscosity index
- Protection against wear, corrosion and foam formation
- Excellent viscosity-temperature behavior
- High thermal and oxidative stability
- Neutral behavior towards sealing materials
- Stable lubricating film under extreme loads in summer
Technical Product Data
| Characteristics | Property | Data | Audit |
|---|---|---|---|
| Colour | gelb | VISUELL | |
| Viscosity at 100 °C | mm²/s | 5,55 | DIN 51562-1 |
| Viscosity at 40 °C | mm²/s | 23,77 | DIN 51562-1 |
| Viscosity Index VI | 187 | DIN ISO 2909 | |
| Brookfield Viscosity at -40 °C | mPa*s | 3100 | ASTM D2983 |
| Brookfield Viscosity at -55 °C | mPa*s | 17200 | ASTM D2983 |
| Copper Strip Test at 121 °C | 1b | ASTM D130 | |
| Density at 20 °C | kg/m³ | 832 | EN ISO 12185 |
| Pourpoint | °C | -75 | DIN ISO 3016 |
