RAVENOL Getriebeoel EPX SAE 80W GL-5

CategoryGear oil for manual transmissions and drive axis

Item number1223201

Specification API GL-5

Oil type Mineral

Recommendation Ford SQM-2C-9002 AA, MAN 342 M1, MB 235.0, MIL-L-2105 D, ZF TE-ML 05A, ZF TE-ML 07A, ZF TE-ML 16B, ZF TE-ML 16C, ZF TE-ML 16D, ZF TE-ML 17B

Application Passenger car, Truck, Agricultural machinery, Oldtimer

RAVENOL Getriebeoel EPX SAE 80 GL 5 was developed to eliminate seasonal transmission oil changes.

RAVENOL Getriebeoel EPX SAE 80 GL 5 guarantees due to the balanced additive combination characteristics like a high pressure absorption capacity, a superior viscosity temperature behaviour, a high oxidation stability, low pour points, a good corrosion protection and non-sludging.

Application Note

RAVENOL Getriebeoel EPX SAE 80 GL 5 is compatible with all name brand transmission oils. No “flushing” required when switching to RAVENOL Getriebeoel EPX SAE 80 GL 5

Use RAVENOL Getriebeoel EPX SAE 80 GL 5 in hypoid gears for hypoid gearbox, manual transmissions, axle drives, distributor and intermediate transmissions in vehicles and working machines.

Characteristics

  • Optimal cold flow property
  • Outstanding wear protection even with short trips in winter
  • High pressure stable lubrication film, thus outstanding wear protection under any stress
  • Reduced transmission noise and the best transmission efficiency under full load, i.e. even with very hot oil
  • Outstanding shearing stability
  • Excellent oxidation stability, no foaming
  • No oil thickening or deposits
  • Extraordinary ageing stability
  • Excellent viscosity-temperature properties
  • Effective wear protection
  • Extraordinary corrosion protection, no rust, won’t harm non-ferrous metals
  • Neutral to sealants, transmissions stay tight, no oil loss

Technical Product Data

PropertyUnitDataAudit
Density at 20 °C kg/m³ 882,0 EN ISO 12185
Colour gelbbraun VISUELL
Viscosity at 100 °C mm²/s 14,3 DIN 51562-1
Viscosity at 40 °C mm²/s 130,3 DIN 51562-1
Viscosity Index VI 108 DIN ISO 2909
Brookfield Viscosity at -26 °C mPa*s 60.100 ASTM D2983
Pourpoint °C -33 DIN ISO 3016
Flashpoint °C 222 DIN EN ISO 2592
Copper Strip Test at 121 °C 1b ASTM D130

All indicated data are approximate values and are subject to the commercial fluctuations.
