RAVENOL Getriebeoel LS SAE 75W-90

Category: Gear oil for manual transmissions and drive axis

Item number: 1222102

Viscosity: 75W-90

Specification: API GL-5 + LS, MIL-L-2105 D

Oil type: Synthetic

Recommendation: GM 1940058, GM 88862624, GM 88862625, GM 93165388, ZF TE-ML 05C, ZF TE-ML 05D

Application: Passenger car, Truck

RAVENOL Getriebeoel LS SAE 75W-90 is a synthetic lubricant for mechanical transmissions.

RAVENOL Getriebeoel LS SAE 75W-90 is designed based on high-quality solvent refined and synthetic base oils with special additive treatment and inhibition for higher stress on manual transmission oils and ensuring trouble-free transmission function.

Application Note

RAVENOL Getriebeoel LS SAE 75W-90 was developed specifically for use in differential gear units with limited slip. It also ensures trouble-free lubrication in self-locking, hypoid geared transmissions.

Characteristics

excellent oxidation stability
excellent protection against rust and corrosion
prevents foaming
outstanding extreme pressure properties
excellent limited slip properties
fuel savings

Technical Product Data

Property	Unit	Data	Audit
Density at 20 °C	kg/m³	870,0	EN ISO 12185
Colour		gelb	VISUELL
Viscosity at 100 °C	mm²/s	17,1	DIN 51562-1
Viscosity at 40 °C	mm²/s	118,3	DIN 51562-1
Viscosity Index VI		158	DIN ISO 2909
Brookfield Viscosity at -40 °C	mPa*s	88.800	ASTM D2983
Pourpoint	°C	-42	DIN ISO 3016
Flashpoint	°C	192	DIN EN ISO 2592
Copper Strip Test at 121 °C		1b	ASTM D130

All indicated data are approximate values and are subject to the commercial fluctuations.
