RAVENOL MOTOGEAR SAE 75W-90 GL-4

Category: Gear oil for manual transmissions and drive axis
Item number: 1250050
Viscosity: 75W-90
Specification: API GL-4
Oil type: Fully synthetic

RAVENOL Motogear SAE 75W-90 GL-4 is a fully synthetic gear oil with a special formulation for extremely stressed gearboxes and rear axles.

RAVENOL Motogear SAE 75W-90 GL-4 is designed on the basis of high-quality synthetic base oils with a special additivation and inhibition to ensure the proper operation of the transmission and the rear axle.

RAVENOL Motogear SAE 75W-90 GL-4 has good high temperature stability with a high load carrying capacity and reduces friction even under extreme operating conditions.

RAVENOL Motogear SAE 75W-90 GL-4 for comfortable operation even at low temperatures.

Application Note

RAVENOL Motogear SAE 75W-90 GL-4 is best for use in highly loaded gearboxes and rear axle - final drive, for which SAE 75W-90 API GL-4 oil is required.

Characteristics

  • High load carrying capacity by a stable lubricating film even at high loads
  • Reduction of friction and wear by special additives
  • A very good corrosion protection and good tolerability to non-ferrous metal
  • A high oxidative stability to prevent oil thickening and deposits
  • Excellent cold flow properties
  • a very good compatibility with elastomers to prevent leaks
  • A very strong protection against rust, corrosion and foaming
  • Excellent EP properties

Technical Product Data

PropertyUnitDataAudit
Density at 20 °Ckg/m³840,0EN ISO 12185
ColourgelbVISUELL
Viscosity at 100 °Cmm²/s16,8DIN 51562-1
Viscosity at 40 °Cmm²/s108,8DIN 51562-1
Viscosity Index VI168DIN ISO 2909
Brookfield Viscosity at -40 °CmPa*s47.000ASTM D2983
Pourpoint°C-54DIN ISO 3016
Flashpoint°C230DIN EN ISO 2592
Copper Strip Test at 121 °C1aASTM D130

All indicated data are approximate values and are subject to the commercial fluctuations.
