RAVENOL Hydraulikoel TS 100 (HLP)

Category: Other hydraulic oil
Item number: 1323107
Viscosity: 100
Specification: DIN 51524-2, ISO 6743-4 HM
Oil type: Mineral
Application: Industry

RAVENOL Hydraulikoel TS 100 (HLP) is optimal alloyed mineral hydraulic oil with a high performance level and a wide application area of the whole industry.

RAVENOL Hydraulikoel TS 100 (HLP) with efficient additives offers an excellent corrosion protection even under extreme loads. The behaviour of sealing materials is neutral.RAVENOL Hydraulikoel TS 100 (HLP) is characterised by good viscosity temperature behaviour, a high aging resistant and a solid corrosion protection.

Application Note

RAVENOL Hydraulikoel TS 100 (HLP) is for universally use in all hydraulic systems.

RAVENOL Hydraulikoel TS 100 (HLP)

is recommended in high performance hydraulic systems with high pressure pumps of all types, in sensitive control systems.

RAVENOL Hydraulikoel TS 100 (HLP) is used for hydraulic systems in agriculture, to supply small gearboxes and for use in circulating systems.

Characteristics

  • a high performance level
  • a very good viscosity temperature behaviour
  • a high aging resistant
  • an excellent corrosion protection
  • a solid corrosion protection
  • neutrality of sealing materials

Technical Product Data

PropertyUnitDataAudit
Density at 20 °Ckg/m³875,0EN ISO 12185
ColourgelbVISUELL
Viscosity at 100 °Cmm²/s11,2DIN 51562-1
Viscosity at 40 °Cmm²/s100,2DIN 51562-1
Viscosity Index VI98DIN ISO 2909
Pourpoint°C-21DIN ISO 3016
Flashpoint°C264DIN EN ISO 2592

All indicated data are approximate values and are subject to the commercial fluctuations.
