RAVENOL Hydraulikoel TS 100 (HLP)

RAVENOL Hydraulikoel TS 100 (HLP) is optimal alloyed mineral hydraulic oil with a high performance level and a wide application area of the whole industry.

RAVENOL Hydraulikoel TS 100 (HLP) with efficient additives offers an excellent corrosion protection even under extreme loads. The behaviour of sealing materials is neutral.RAVENOL Hydraulikoel TS 100 (HLP) is characterised by good viscosity temperature behaviour, a high aging resistant and a solid corrosion protection.

Application Note

RAVENOL Hydraulikoel TS 100 (HLP) is for universally use in all hydraulic systems.

RAVENOL Hydraulikoel TS 100 (HLP)

is recommended in high performance hydraulic systems with high pressure pumps of all types, in sensitive control systems.

RAVENOL Hydraulikoel TS 100 (HLP) is used for hydraulic systems in agriculture, to supply small gearboxes and for use in circulating systems.

Characteristics

  • a high performance level
  • a very good viscosity temperature behaviour
  • a high aging resistant
  • an excellent corrosion protection
  • a solid corrosion protection
  • neutrality of sealing materials

Technical Product Data

PropertyUnitDataAudit
Colour gelb VISUELL
Viscosity at 100 °C 11,2 mm²/s DIN 51562-1
Viscosity at 40 °C 100,2 mm²/s DIN 51562-1
Viscosity Index VI 98 DIN ISO 2909
Density at 20 °C 875,0 kg/m³ EN ISO 12185
Flashpoint 264 °C DIN EN ISO 2592
Pourpoint -21 °C DIN ISO 3016
