RAVENOL Hydraulikoel TS AF 46

Category Other hydraulic oil

Item number 1323125

Viscosity 46

Specification DIN 51524-2

Recommendation FZG-Test A 8,3/90, MAN N 698, SEB 181.222, SEB 181.226, Timken-Test nach DIN E 51434, Vickers-Pumpentest

Application Industry

RAVENOL Hydraulikoel TS AF 46 is a zinc and ash-free compounded oil based phosphorous and sulfur intended especially for use in the metal industry. Excellent results were achieved in the Timken test. Through the addition of selected ingredients, RAVENOL Hydraulikoel TS AF 46 has excellent wear protection, good oxidation stability and has a long service life even under extreme conditions. Compatibility with sealants is neutral. Furthermore, the additives provide corrosion protection and prevent foaming.

RAVENOL Hydraulikoel TS AF 46 exceeds the requirements of DIN 51 524 part 2 for HLP hydraulic oils.

Application Note

RAVENOL Hydraulikoel TS AF 46 is for use as a hydraulic fluid in the metal industry, if zinc and ash-free hydraulic oil and the specification DIN 51 524, Part 2 is required.


  • High performance level
  • Good oxidation stability
  • High resistance to ageing
  • Outstanding wear protection
  • High level of corrosion protection
  • Neutral to sealants
  • No foaming

Technical Product Data

Density at 20 °C 862,0 kg/m³ EN ISO 12185
Colour gelb VISUELL
Viscosity at 100 °C 7,2 mm²/s DIN 51562-1
Viscosity at 40 °C 46,4 mm²/s DIN 51562-1
Viscosity Index VI 118 DIN ISO 2909
Pourpoint -36 °C DIN ISO 3016
Flashpoint 218 °C DIN EN ISO 2592
