Category:
Other hydraulic oil
Item number:
1323204
Viscosity:
32
Specifications:
AFNOR NFE 48-603 HV,
AFNOR NFE 48-690/1,
CETOP RP 91H HV,
DIN 51524-3,
GB 111118.1 L-HV,
ISO 11158 HV,
ISO 6743-4 HV,
JCMAS HK VG32W,
SAE MS 1004,
US Steel 127,
US Steel 136
Oil type:
Mineral
Recommendations:
Bosch Rexroth RE 90220,
Eaton Vickers I-286-S,
Eaton Vickers M-2950-S,
Fives Cincinnati P-68,
GM LH-03-1-04,
GM LS-2,
Parker Denison HF-0,
Parker Denison HF-1,
Parker Denison HF-2,
Sauer-Danfoss 520L0463
Application:
Industry
RAVENOL Hydraulikoel TSX 32 (HVLP) is high quality multi-grade hydraulic oil type HVLP based on special selected solvent refined basic oils. It is characterised by a high stable viscosity index and a solid corrosion protection. Efficient additives offer an excellent corrosion protection even under extreme loads. The behaviour of sealing materials is neutral.
Application instructions
RAVENOL Hydraulikoel TSX 32 (HVLP) is suitable for heavy loaded hydraulic machines of the industry, for earth moving machines and agricultural machines. Preferred use in case of great variations of the operation temperature. No use in case of silver and/or silver-coated components in the hydraulic machines.
Characteristics
- A high and stable viscosity index
- An excellent corrosion protection
- An excellent protection against wear
- A very good air and water separation behaviour to prevent foam formation
- Neutral behaviour towards sealing of plastics
- A very low pour point
Technical Product Data
| Characteristics | Property | Data | Audit |
|---|---|---|---|
| Colour | gelb | VISUELL | |
| Sulphated Ash | %wt. | 0,06 | DIN 51575 |
| tbn | mg KOH/g | 0,4 | ASTM D2896 |
| Viscosity at 100 °C | mm²/s | 6,3 | DIN 51562-1 |
| Viscosity at 40 °C | mm²/s | 32,0 | DIN 51562-1 |
| Viscosity Index VI | 152 | DIN ISO 2909 | |
| Density at 20 °C | kg/m³ | 845,0 | EN ISO 12185 |
| Flashpoint | °C | 227 | DIN EN ISO 2592 |
| Pourpoint | °C | -39 | DIN ISO 3016 |
