RAVENOL Kompressorenoel VDL 68

Category: Industrial oil
Item number: 1330099
Viscosity: 68
Specification: DAB, DAG, DAH, DIN 51506 VDL, ISO/DP 6521
Oil type: Mineral
Application: Industry

RAVENOL Kompressorenoel VDL 68

is a special ageing-resistant-lubricating oils offering minimal coking based on high-quality age-resistant base oils with ash less additives to improve corrosion protection and ageing stability and meets the high requirements of DIN 51 506.

RAVENOL Kompressorenoel VDL 68

has a good adhesion, is water repellent and wear reducing. As many compressors operate at high temperatures, the oil should have good aging resistance at very low residue formation.

RAVENOL Kompressorenoel VDL 68

provides a secure lubrication not only in the upper temperature range, also in the cold state of the compressor to achieve a reduction of wear. By selected and coordinated additive composition the tendency to coking and the formation of flammable residues is minimized.

Application Note

RAVENOL Kompressorenoel VDL 6

can be used in stationary and mobile compressors with discharge temperatures up to 220°C.

RAVENOL Kompressorenoel VDL 6

can also be used for lubrication of engines and diesel engines where the manufacturer does not stipulate any HD motor oil.

RAVENOL Kompressorenoel VDL 6

is not recommended for ATLAS COPCA GA xx series compressors.

Technical Product Data

PropertyUnitDataAudit
ColourgelbVISUELL
Viscosity at 100 °Cmm²/s9,0DIN 51562-1
Viscosity at 40 °Cmm²/s69,0DIN 51562-1
Viscosity Index VI104DIN ISO 2909
Density at 20 °Ckg/m³868EN ISO 12185
Flashpoint°C262DIN EN ISO 2592
Pourpoint°C-30DIN ISO 3016

All indicated data are approximate values and are subject to the commercial fluctuations.
