RAVENOL Getriebeoel MZG SAE 90 GL 4

RAVENOL Getriebeoel MZG SAE 90 GL 4 1 L- 1223102-001
ART.-NR. 1223102-001
RAVENOL Getriebeoel MZG SAE 90 GL 4 4 L- 1223102-004
ART.-NR. 1223102-004
RAVENOL Getriebeoel MZG SAE 90 GL 4 10 L- 1223102-010
ART.-NR. 1223102-010
RAVENOL Getriebeoel MZG SAE 90 GL 4 20 L- 1223102-020
ART.-NR. 1223102-020
RAVENOL Getriebeoel MZG SAE 90 GL 4 20 L- 1223102-B20
ART.-NR. 1223102-B20
RAVENOL Getriebeoel MZG SAE 90 GL 4 1000 L- 1223102-700
ART.-NR. 1223102-700
  • 1 L | 1223102-001
  • 4 L | 1223102-004
  • 10 L | 1223102-010
  • 20 L | 1223102-020
  • 20 L | 1223102-B20
  • 1000 L | 1223102-700
Viscosity
90
Specifications
API GL-4
MIL-L-2105D
Fabrication
mineral
Categories
Gear oils for manual transmissions
Recommendations
MAN 341 Typ Z-1
MAN 341 Typ E-1
MB 235.11
Ford SQM-2C-9008 A
ZF TE-ML 02B, 16A, 17A, 19A

EP transmission oil (Extreme Pressure) for manual transmissions, transfer cases, steering gears as well as axle transmissions under standard conditions.

RAVENOL Getriebeoel MZG SAE 90 GL 4 contains high quality base oils with a balanced combination of ingredients. This ensures a high load carrying capacity, wear protection and oxidation stability.

Above-average viscosity-temperature properties, low pour points and last but not least the prevention of foaming enable use in various operating conditions.

Application Notes

RAVENOL Getriebeoel MZG SAE 90 GL 4 is suitable for the lubrication of manual transmissions, differential and steering gears in motor vehicles, which require EP transmission fluid according to manufacturer specifications.

Characteristics

RAVENOL Getriebeoel MZG SAE 90 GL 4 offers:

  • Well adhering and pressure resistant lubricating films
  • Excellent oxidation stability
  • Above-average viscosity-temperature properties
  • Anti-wear effect
  • Good air release characteristics, no foaming
  • Neutral to metal and sealants
PropertyUnitDataAudit
Density at 20°Ckg/m³884,0EN ISO 12185
Colouryellowvisual
Viscosity at 100°Cmm²/s14,1DIN 51562-10
Viscosity at 40°Cmm²/s135,9DIN 51562-10
Viscosity index VI101DIN ISO 2909
Brookfield ViscositymPa*s125.500ASTM D 2983
Pourpoint°C-33DIN ISO 3016
Flash point (COC)°C240DIN ISO 2592
Copper Strip Test1aASTM D130
