RAVENOL SCR PAO 46 Screw Kompressorenöl

RAVENOL SCR PAO 46 Screw Kompressorenöl 20 L- 1330315-020
ART.-NR. 1330315-020
RAVENOL SCR PAO 46 Screw Kompressorenöl 20 L- 1330315-B20
ART.-NR. 1330315-B20
RAVENOL SCR PAO 46 Screw Kompressorenöl 1000 L- 1330315-700
ART.-NR. 1330315-700
  • 20 L | 1330315-020
  • 20 L | 1330315-B20
  • 1000 L | 1330315-700
Specifications
ISO VG Klasse 46
Categories
Hydraulic Oils / Compressor Oils
Recommendations
DIN 51 506 VDL

RAVENOL SCR PAO 46 Screw Kompressorenöl is fully synthetic compressoroil with ISO VG Class 46, which is specifically designed to provide effective lubrication in rotary screw air compressors.

RAVENOL SCR PAO 46 Screw Kompressorenöl is also specifically designed to significantly extend service life in rotary screw compressors.

RAVENOL SCR PAO 46 Screw Kompressorenöl has excellent resistance to oxidative breakdown caused by exposure to air at high discharge temperatures it has excellent thermal stability for reducing carbon deposit formation.

RAVENOL SCR PAO 46 Screw Kompressorenöl shows good protection against wear, protects against rust and corrosion. Low volatility reduces oil carry-over into the air system. Reduces fluid consumption.

The full benefits of a change to RAVENOL SCR PAO 46 Screw Kompressorenöl will only be realized by minimizing contamination with the previously used oil. Certain makes of compressors do not permit complete draining, so if the drained oil is heavily oxidized (shown by significant increase in the oil’s total acid number and viscosity), recharging with RAVENOL SCR PAO 46 Screw Kompressorenöl may not result in optimum performance and fluid service life.

RAVENOL SCR PAO 46 Screw Kompressorenöl has excellent oxidation stability, corrosion, deposit control and low volatility and provides up to 8,000 hours of continuous worry-free service for lubrication, sealing and effective heat removal for efficient compressor performance.

Application Notes

RAVENOL SCR PAO 46 Screw Kompressorenöl wird für den Einsatz in Schraubenkompressoren empfohlen.

Characteristics

RAVENOL SCR PAO 46 Screw Kompressorenöl offers:

  • High oxidation stability.
  • Excellent protection against rust and corrosion.
  • Excellent resistance to oxidative breakdown caused by exposure to air at high discharge temperatures
  • Higher thermal stability reduces carbon deposit formation
  • Improved viscosity index and good low temperature properties
  • Good protection against wear
  • Protects against rust and corrosion
  • Low volatility reduces oil carry-over into the air system
  • Reduces fluid consumption
PropertyUnitDataAudit
Density at 20°Ckg/m³840,0EN ISO 12185
Colourhellgelbvisual
Viscosity at 100°Cmm²/s8,3DIN 51 562
Viscosity at 40°Cmm²/s45,4DIN 51 562
Viscosity index VI160DIN ISO 2909
Pourpoint°C-66DIN ISO 3016
Flash point (COC)°C240DIN ISO 2592
Total Acid Number TANm KOH/g0,14ASTM D664
Water Separation at 54°C (min)ml40-40-0 (15)ASTM D1401
corrosion prevention-
Copper Corrosion3h at 100°C1aASTM D130
A- distilled waterBestandenASTM D665
B - Synthetic SeawaterBestandenASTM D665
Residue and Ash:-
Coke Residue, % (Conradsontest)<0,1ASTM D524
Foam Sequence Iml0/0ASTM D892
Foam Sequence IIml0/0ASTM D892
Foam Sequence IIIml0/0ASTM D892
