RAVENOL MOTOGEAR SAE 80W-90 GL-4

Category: Gear oil for manual transmissions and drive axis
Item number: 1250055
Viscosity: 80W-90
Specification: API GL-4
Oil type: Mineral
Application: Motorcycle

RAVENOL MOTOGEAR SAE 80W-90 GL-4 is a transmission fluid on a mineral oil basis with special effective additives for manual transmissions. A high load-carrying capacity guarantees optimum gearbox lubrication even at high temperatures.

RAVENOL MOTOGEAR SAE 80W-90 GL-4 ensures a strong oil film for lubrication even under the most extreme dynamic conditions.

RAVENOL MOTOGEAR SAE 80W-90 GL-4 reduces friction, prevents wear and corrosion.

Application Note

RAVENOL MOTOGEAR SAE 80W-90 GL-4 is suitable for use in manual transmissions for 2- and 4-stroke motorcycles if oil according to SAE 80W-90 API GL-4 is specified.

Characteristics

  • Highly adhesive and pressure resistant lubricant films
  • Excellent oxidation stability
  • Above-average viscosity-temperature characteristics
  • Wear-preventing effect
  • A good air release property, no foaming
  • Neutral behaviour towards metal and sealing compounds

Technical Product Data

PropertyUnitDataAudit
Density at 20 °Ckg/m³879,0EN ISO 12185
ColourgelbbraunVISUELL
Viscosity at 100 °Cmm²/s14,0DIN 51562-1
Viscosity at 40 °Cmm²/s126,9DIN 51562-1
Viscosity Index VI108DIN ISO 2909
Brookfield Viscosity at -26 °CmPa*s45.600ASTM D2983
Pourpoint°C-33DIN ISO 3016
Flashpoint°C244DIN EN ISO 2592
Copper Strip Test at 121 °C1bASTM D130

All indicated data are approximate values and are subject to the commercial fluctuations.
