RAVENOL Gear Trans Synth GTS SAE 75W-90

1 L | 1221122-001
4 L | 1221122-004
10 L | 1221122-010
20 L | 1221122-020
20 L | 1221122-B20
60 L | 1221122-060
60 L | 1221122-D60
208 L | 1221122-D28

Category Gear oil for manual transmissions and drive axis

Item number 1221122

Specification API GL-4, API GL-5, Mil-PRF-2105 E, MT-1, SAE J2360

Oil type Vollsynthetisch

Approvals (ZF006038), MB-Freigabe 235.8, Scania STO 1:1 G, Scania STO 2:0 A FS, ZF TE-ML 02B, ZF TE-ML 05A, ZF TE-ML 12L, ZF TE-ML 12N, ZF TE-ML 16F, ZF TE-ML 17B, ZF TE-ML 19C, ZF TE-ML 21A

Recommendation Arvin Meritor 076-N, DAF, DFS93K219.01, IVECO, MACK GO-J, MAN 341 Z-2, MAN 342 Typ M3, MAN 342 Typ S1, RENAULT, VOLVO 97312, ZF TE-ML 07A, ZF TE-ML 08, ZF TE-ML 12B, ZF TE-ML 13

RAVENOL GEAR TRANS SYNTH GTS SAE 75W-90 is a fully synthetic axle drive oil based on the latest fully synthetic components for commercial vehicles.

RAVENOL GEAR TRANS SYNTH GTS SAE 75W-90is designed on the basis of high quality synthetic base oils with special additivation and inhibition, which ensure proper functioning of the gearbox. It was specially developed to meet the latest requirements of axle drive manufacturers, especially according to Daimler specification 235.8.

Application Note

RAVENOL GEAR TRANS SYNTH GTS SAE 75W-90 is excellent for use in heavily loaded axle drives of commercial vehicles.

RAVENOL GEAR TRANS SYNTH GTS SAE 75W-90 is suitable for non-synchronized manual transmissions, for which an oil according to API GL-5 or GL-4 is prescribed.

Characteristics

high additive reserves for prolonged oil change intervals according to the manufacturer instructions
excellent cold flow properties
good wear protection protects the gearbox
Fuel savings even with short distances in low outside temperatures
stable lubricating film even under high stress
extreme low pour point
Can be used at changing temperatures due to the high viscosity index

Technical Product Data

Property	Unit	Data	Audit
Density at 20 °C	868,0		EN ISO 12185
Colour	gelb		VISUELL
Viscosity at 100 °C	15,8	mm²/s	DIN 51562-1
Viscosity Index VI	158		DIN ISO 2909
Pourpoint	-57	°Celsius	DIN ISO 3016
Seq. I at 24 °C	0/0		ASTM D892
Seq. II at 93,5 °C	0/0		ASTM D892
Viscosity at 40 °C	106,8	mm²/s	DIN 51562-1
Copper Corrosion (24h/120 °C)	1a		ASTM D130
