RAVENOL Sperrdiff.-Getr.-Oel LS 90

CategoryGear oil for manual transmissions and drive axis

Item number1223302

Specification API GL-5, MIL-L-2105 D

Oil type Mineral

Recommendation Ford Spezifikation, ZF TE-ML 05C, ZF TE-ML 12C, ZF TE-ML 16E, ZF TE-ML 21C

Application Passenger car, Truck, Agricultural machinery

RAVENOL Sperrdiff.-Getr.-Oel LS 90 is locking differential hypoid gear oil that meets the extremely stringent requirements in differential gears and differential lock.

RAVENOL Sperrdiff.-Getr.-Oel LS 90 ensures good adhesion, high pressure-resistant lubricating film and offers excellent "limited slip" (LS) properties against unwanted slip-slip properties. Greatly offset hypoid gear pairs are also under severe operating conditions effectively protected against wear.

Application Note

RAVENOL Sperrdiff.-Getr.-Oel LS 90 GL-5 was specially developed for use in differential with high requirements on differential with differential lock.

Characteristics

  • Extremely high load carrying capacity
  • Excellent wear protection by EP agents
  • Excellent "limited slip" – Features
  • Excellent resistance to aging
  • High oxidation resistance even under high thermal stress
  • Good foam / air separation and behave well at high speeds
  • Neutrality towards non-ferrous metals and seals
  • Excellent viscosity-temperature behavior

Technical Product Data

PropertyUnitDataAudit
Density at 20 °C kg/m³ 889,0 EN ISO 12185
Colour gelbbraun VISUELL
Viscosity at 100 °C mm²/s 17,6 DIN 51562-1
Viscosity at 40 °C mm²/s 177,3 DIN 51562-1
Viscosity Index VI 108 DIN ISO 2909
Brookfield Viscosity at -12 °C mPa*s 12.400 ASTM D2983
Pourpoint °C -30 DIN ISO 3016
Flashpoint °C 214 DIN EN ISO 2592
Copper Strip Test at 121 °C 1b ASTM D130

All indicated data are approximate values and are subject to the commercial fluctuations.
